Safran announces the reason for their IMOCA 60's keel foil breakage

Thursday December 20th 2012, Author: James Boyd, Location: France

Following the withdrawal of the Safran IMOCA 60 skippered by Marc Guillemot shortly after the start of the Vendée Globe round-the-world race, a group of three Safran specialists, in mechanics, quality and materials & processes, along with the team involved in development of the boat's keel (naval architects, designers and manufacturers) to determine the causes of the broken keel.

Analysis

The specialists analysed the break in the keel fin by microscopic observations to determine why it failed. Samples were also taken from the metal to check if its characteristics matched the values used for strength calculations. At the same time, other experts calculated the loads experienced by the keel, based on observations of the break, and compared them to the standard loads used as a basis for its design.

Results

The investigation was able to exclude the possibility of a break due to a collision with an 'unidentified floating object'. It also noted that there were no metallurgical defects, and that the welds showed no anomalies that could explain the break. The investigation shows that the break was due to damage caused by metal fatigue, engendered by repeated shocks from contact with waves. There are no indications of a high-frequency vibration phenomenon.

A close look at the break spotlights the high loads due to the extreme sea conditions experienced by Safran over the last year, during the Transat Jacques Vabre 2011, her Round Britain record attempt, and training runs for the Vendée Globe. The analysis confirms that the loads experienced by the keel were undoubtedly far higher than the standard values used by the design teams, as well as the values calculated from the shock recordings during the Transat Jacques Vabre 2009.

"The Safran Open 60 monohull ocean racer has undergone significant technical changes since 2010 to boost its performance," said Gérard Le Page, President of the Safran Sailing Team. "Facing increasingly fierce competition, the boat is subjected to ever-higher levels of stress, even under very sustained conditions. The shocks experienced by the boat and its appendages were also more violent, in particular exceeding the estimates used by the design team. However, it is not only success, but also failure that drives improvements as we seek to move forward."

Safran will take advantage of the lessons learned through this investigation to design a new keel and work with Marc Guillemot to prepare for the next major race, the Transat Jacques Vabre next autumn. Safran will of course make available all conclusions of this investigation to the IMOCA Technical Committee, so that all shipowners and skippers can benefit from the lessons learned.

Any competition entails risks, and the skippers who face these risks day after day have largely earned our admiration.
